Solar Panel 360w 350w 340w 330w 335w 320w Poly Hanwha Solar Panel

  • We Are the Manufacturer!
  • Sample & OEM & ODM are available.
  • Great finance support
  • Great service support
  • Great assurance support
Glass

Antireflective glass
Translucency of normal luminance is increased 2%
Module efficiency is increased 2%
Self-clean function
Service life 25 years

Solar Cell

High efficiency 5BB/12BB PV cell
Uniform color
Anti-PID
Germany standard Cell
Full test

Frame

Stock-size
Silvery and black
thickness 30/35/40mm
stress test

Junction box

Conventional standalone edition and engineering custom edition
Quality diode ensures module running safety
IP67 protection level
Heat dissipation
Long service life

Key Attributes

TypePERC,Half Cell,Bifacial, Double-glass, All Black, MWTMaterialMonocrystalline Silicon
Cell size158.75mmx158.75mm (6.25inx6.25in)Panel Efficiency18.6%
TypeStandard Solar PanelPanel Dimensions158.75mmx158.75mm (6.25inx6.25in)
TPT back sheetWhite or blackModel NumberBSM350P-72
Junction BoxIP67 Ratedsolar panelhanwha solar panel
Applicationsolar systemAluminium alloy frameSilvery or black
Weight22.5 Kg (49.6 Lb)ConnectorPV
Fire safety classClass A

Parameter

ModelBSM335P-72BSM340P-72BSM345P-72BSM350P-72BSM355P-72
Rated Maximum Power at STC335W340W345W350W355W
Open Circuit Voltage(Voc/V)46.346.546.746.947.0
Maximum Power Voltage(Vmp/V)37.938.238.438.538.7
Short Circuit Current(Isc/A)9.369.459.59.69.69
Maximum Power Current(Imp/A)8.848.909.009.099.17
Module Efficiency17.3%17.5%17.8%18.0%18.3%
Standard Test Condition(STC)Irradiance 1000w/m2, Cell Temperature 25 Centigrade, Air Mass 1.5
