Trinasolar 320w 330w 340w 350watt Solar Panels Price for Qatar Market Wholesale Solar Panel for 230v

  • We Are the Manufacturer!
  • Sample & OEM & ODM are available.
  • Great finance support
  • Great service support
  • Great assurance support
Glass

Antireflective glass
Translucency of normal luminance is increased 2%
Module efficiency is increased 2%
Self-clean function
Service life 25 years

Solar Cell

High efficiency 5BB/12BB PV cell
Uniform color
Anti-PID
Germany standard Cell
Full test

Frame

Stock-size
Silvery and black
thickness 30/35/40mm
stress test

Junction box

Conventional standalone edition and engineering custom edition
Quality diode ensures module running safety
IP67 protection level
Heat dissipation
Long service life

Key Attributes

Cell size125mmx125mm (4.92inx4.92in)TypePERC
Panel Efficiency19%Weight21 KG
Panel Dimensions1956*992*40mm (77.01*39.06*1.57in) CertificateTUV/IEC61215/ IEC61730/CEC/ CE/ISO/INMETRO
Model NumberBSM350P-72TypeStandard Solar Panel
TPT back sheetWhite or blackSolar cell(mm)5BB Poly 156*156
 Junction BoxIP67 RatedAluminium alloy frameSilvery or black
Fire safety classClassAWarranty25 Years, 25Years
Application classClass A

Parameter

ModelBSM335P-72BSM340P-72BSM345P-72BSM350P-72BSM355P-72
Rated Maximum Power at STC335W340W345W350W355W
Open Circuit Voltage(Voc/V)46.346.546.746.947.0
Maximum Power Voltage(Vmp/V)37.938.238.438.538.7
Short Circuit Current(Isc/A)9.369.459.59.69.69
Maximum Power Current(Imp/A)8.848.909.009.099.17
Module Efficiency17.3%17.5%17.8%18.0%18.3%
Standard Test Condition(STC)Irradiance 1000w/m2, Cell Temperature 25 Centigrade, Air Mass 1.5
