Solis Hybrid Inverter 16kw Solis S6-EH2P (10-16) K03-NV-YD-L-US Hybrid Solar Inverter 10KW-16KW For UAS CA

  • We Are the Manufacturer!
  • Sample & OEM & ODM are available.
  • Great finance support
  • Great service support
  • Great assurance support

Key Attributes

Output TypeSingle, DUAL, Triple, Quad, Multiple, Three PhaseTypeDC/ACInverters
Brand NameSOLISInverter Efficiency 99.9%
Place of OriginGuangdong, ChinaModel NumberS6-EH2P (10-16) KO3-NV-YD-L-US
Input Voltage48VOutput Voltage 220V/230V/240V
Output Current2-10AOutput Frequency50/60Hz
Size459x845x313Mm (18.07×33.27×12.32in)Weight 56kg(123.46lb)
Working Temperature Range:-45~65℃Protection DegreeIP67
Communication with BMS:2.4 GHz Proprietary RF(Nordic)Nighttime power consumption<50mW
Output Voltage220V/230V/240VOutput Current5-10A
Output Frequency50/60HzSize  459x845x313 mm
CertficateCE/IEC/ULWarranty 10 Years

Product Parameters

ModelS6-EH2P10K03-NV-YD-L-USS6-EH2P12K03-NV-YD-L-USS6-EH2P14K03-NV-YD-L-USS6-EH2P16K03-NV-YD-L-US
Input DC (PV side)
Max input voltage550V
Normal Voltage380V
Starting voltage100V
MPPT voltage range100V-450V
Max input current per MPPT40A
Max short-circuit current per MPPT50A
Number of MPPTs / Number of strings per MPPT3/2
Battery
Battery TypeLithium Ion / Lead-Acid
Battery Voltage Range40V-60 V
Maximum Charge/Discharge Current208 A250 A290 A290 A
CommunicationCAN / RS485
Number of Batteries per InverterSee Battery Compatibility Sheet
AC Output (Mains)
Nominal Output Power10KW12KW14KW16KW
Maximum Apparent Output Power10KVA12KVA14KVA16KVA
Nominal Output Voltage220V
Nominal Grid Frequency60HZ
Nominal Grid Output Current45.5 A54.4A63.6A72.7A
Maximum Output Current45.5 A54.4A63.6A72.7A
THDi< 3%
AC Input (Mains)
Input voltage range193.6 – 242 V
Maximum input current200 A
Frequency range59.5 – 60.5 Hz
AC Output (Backup)
Nominal Output Power10 kW12 kW14 kW16 kW
Maximum Apparent Output Power2 times the rated power, for 10 s
Backup Response Time< 4 ms
Phase PowerL1/L2/N(PE), 120 V / 240 V (Split Phase)
Nominal Output Voltage (L1-L2)220 V
AC Output Voltage Range193.6 – 242 V
Nominal Frequency60 Hz
Frequency Range55 – 65 Hz
Nominal Output Current45.5 A54.5 A63.6 A72.7 A
Maximum Output Over Current Protection, 10 sec91 A109 A127 A145 A
Max. continuous AC pass-through200 A
Maximum allowable phase imbalance50%
Backup support configurationsDedicated and whole-house loads
Power factor> 0.99 (0.8 leading to 0.8 lagging)
THDv (@linear load)< 3%
Input Generator
Maximum input power:24 kW
Maximum input current:100 A
Nominal input frequency:60 Hz
