Brand New Sungrow Hybrid Inverter SH3.0RS-SH6.0RS Max Output Power 10kw on Grid Inverter Best Grid Tie Solar Power System

  • We Are the Manufacturer!
  • Sample & OEM & ODM are available.
  • Great finance support
  • Great service support
  • Great assurance support
FLEXIBLE APPLICATION

80~460 V wide battery voltage range
Ideal for both retrofitting and new installations
Built-in smart PID recovery function

ENERGY INDEPENDENCE

Seamless transition to backup mode, for protection against power outages
Fast Charging or discharging, enabling higher self-consumption results
Built-in EMS with advanced customization

USER FRIENDLY SETUP

Plug and play installation
iSolarCloud monitoring available on App and Web
Lightweight and compact, optimized for heat-dissipation

SMART MANAGEMENT

Real time data (10 seconds refresh sample)
24/7 live monitoring both online and with integrated display
Online IV curve scan and diagnosis

Key Attributes

Output TypeSingleTypeDC/AC Inverters
Brand NameSungrowInverter Efficiency98.7%
Place of OriginChinaModel NumberSH3.0/3.6/4.0/5.0/6.0RS
Input Voltage600VOutput Voltage230V
Output Current27.3AOutput Frequency50Hz/45-55Hz
 Size460*540*170mm (18.11*21.26*6.69in) Weight 490*340*170 mm
Product nameSungrow Solar InverterInvertertypeOn grid inverter
Maxoutput power10kwApplicationGrid Tie Solar Power System
MPPT number2MaxPVstrings2
Output typesingle phaseMonitoringWIFI/Ethernet/RS485
 Protection Degree IP65AC short circuit protection Yes

Product Parameters

ype designationSH3.0RSSH3.6RSSH4.0RSSH5.0RSSH6.0RS
Input (DC)
Recommended max. PV input power10000 Wp10700 Wp11000 Wp12000 Wp13000 Wp
Max. PV input voltage600 V
Min. PV input voltage / Startup input voltage40 V / 50 V
Rated PV input voltage360 V
MPP voltage range40V – 560 V
No. of independent MPP inputs2
No. of PV strings per MPPT1 / 1
Max. PV input current32 A (16 A/16 A)
Max. DC short-circuit current40 A (20 A/20 A)
Max. current for input connector20A

Battery Data
Battery typeLi-ion battery
Battery voltage80V – 460V
Max charge / discharge current30A / 30A
Max charge / discharge power6600W

Input / Output (AC)
Max. AC power from grid10000 VA10700 VA11000 VA12000 VA13000 VA
Rated AC output power3000 W3680 W4000 W5000 W6000 W
Max. AC output apparent power3000 VA3680 VA4000 VA5000 VA6000 VA
Max. AC output current13.7 A16 A18.2 A22.8 A27.3A
Rated AC voltage220 / 230 / 240 V
AC voltage range154 V – 276 V
Rated grid frequency50 Hz / 60 Hz
Grid frequency range45 – 55 Hz / 55 – 65 Hz
Harmonic (THD)<3 % (of rated power)
Power factor at Rated power / Adjustable power factor>0.99 at default value at rated power
Feed-in phases / connection phases1 / 1

Efficiency
Max. efficiency / European efficiency97.4 % / 97.0 %97.5 % / 97.1 %97.6 % / 97.2 %97.7 % / 97.3 %97.7 % / 97.3 %

Backup Data （off-grid mode）
Rated voltage220 V / 230 V / 240 V (±2 %)
Frequency range50 Hz / 60 Hz (±0.2 %)
Output voltage harmonic (THD)< 2 %
Switch time to emergency mode< 10 ms
Rated output power3000W / 3000VA3680W / 3680VA4000 W / 4000 VA5000W / 5000VA6000W / 6000VA
Peak output power8400 VA, 10s

Protection & Function
Grid monitoringYes
DC reverse polarity protectionYes
AC short-circuit protectionYes
Leakage current protectionYes
DC switch(solar)Yes
DC fuse(battery)Yes
Surge ProtectionDC Type II /AC Type II
PID recovery functionYes
Parallel operation on grid port / Max. No of invertersMaster-slave mode / 5
Battery input reverse polarity protectionYes

General Data
Topology (Solar / Battery)Transformerless / Transformerless
Degree of protectionIP65
Dimensions (W * H * D)490 * 340 * 170 mm
Weight18.5 kg
Mounting methodWall-mounting bracket
Operating ambient temperature range -25 ℃ to 60 ℃
Allowable relative humidity range0 % – 100 %
Cooling methodNatural convection
Max. operating altitude4000 m
Noise emission< 45dB(A)
DisplayLED digital display & LED indicator
Communication RS485 / Ethernet / WLAN / CAN
DI / DODI * 4 / DO * 1 / DRM
DC connection typeMC4 (PV) / Sunclix (Battery)
AC connection typePlug and Play
Grid complianceIEC/EN 62109-1, IEC/EN 62109-2, IEC62116, IEC61727, IEC/EN 61000-3-11, IEC/EN 61000-3-12, EN 62477-1, AS/NZS 4777.2:2020, EN 50549-1, CEI 0-21, G98 / G99, UNE 217002:2020, NTS V2 TypeA, C10/26
