Black Glass 50W-300W Solar PV Panel Range for Home Roof RV Camping & Motorhome balcony & battery use
Key Attributes
| Cell size | 182mmx182mm (7.17inx7.17in) | Type | hbc |
| Panel Efficiency | 24.4% | Connector | MC Compatible Connector |
| Panel Dimensions | 770*1170*30mm (30.31*46.06*1.18in) | Frame Color | Color Silvery BLACK |
| Model Number | eRigid M200W | Type | Standard Solar Panel |
| Product name | 12v battery Top quality solar panel sunpower cell for home use | Solar cell | SunPower IBC back contact |
| Certificate | CE ROHS SG S | Application | solar panel for home use rv camping motorhome trailers marine boat |
| Backing Color | white | Frame | Anodized Alluminium Alloy |
| Cell Type | 125 5inch solar cell |
Product Description
| Model No. | eRigid M200W |
| Product Name | Top quality 200w solar pv panel Longi back contact cell ce rohs certified for 24v battery home use rv camping motorhome |
| Maximum Power[Wp] | 200 |
| Solar Cell | Longi Back Contact Cell |
| Cell Array[Pcs] | 4*12 |
| Cell Efficiency | 25.8% |
| Size[mm] | 770*1170*30mm |
| Size[inch] | 26.8*56.9 |
| Max Power Voltage Vmp[V] | 33.66 |
| Max Power Current Imp[A] | 5.95 |
| Open Circuit Voltage Voc[V] | 39.7 |
| Short Circuit Current Isc[A] | 6.30 |
| Net.Weight[kg] | 10.8 |
| Power tolerance[%] | ±3% |
| NOCT[℃] | 45±2 |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.3 |
| Temperature Coefficient Voc[[%/K] | -1.74mV |
| Temperature Coefficient Isc[[%/K] | 0.05 |
| Maximum System Voltage[V] | 1000 V |
| Maximum Reverse Current[V] | 20A |
| Certification | CE ROHS |
| Surface/Backsheet | Glass/silver frame/white backsheet |
| Cables and Connectors | Jbox IP65,2bypass diode,0.9m*4mm2 cable and 1 pair of MC4 connector |
| Standard Test Conditions | STC: 1000W/m², AM 1.5 and cell temp 25°C |
| Package | 1pcs/carton box and plywood pallet |
