100W & 150W Solar Panel with PERC Technology for Small Home Solar System & Air Conditioner Installation
Hot sale 100 Watt 12 Volt monocrystalline Solar Panel Kit for solar home system home air conditioner
High Quality Solar Panel Utilizing Grade A Solar Cells , with Positive Power Output Tolerance
25 Year Power Output Warranty, Guaranteed Power Output for 25 Years Minimum (Solar Panel Only)
MC4 connector, Perfect for Charging Most 12-Volt and 24-Volt Batteries (5 Year Warranty)
Automactically soldering machine,A grade mono PERC solar cell,high efficiency 21.3% or more;
Strict quality control and IV EL test;
Good low light performance for a grade solar cell.
Key Attributes
| Cell size | 158.75mmx158.75mm (6.25inx6.25in) | Type | PERC |
| Panel Efficiency | 100w | Type | Standard Solar Panel |
| Panel Dimensions | 765*680*30mm (30.12*26.77*1.18in) | Certificate | CE IEC ROHS LVD S GS |
| Model Number | eRigid M100w-18v | Cell | A grade mono solar cell |
| Product name | solar panel 100w for home air conditioner | Maximum Power | 100w solar modules |
| Solar panel | solar panel 100w for camping rv marine boat | Warranty | 5years |
| Backsheet Color | white | Feature | most popular size for off grid solar system |
Product Specification
| Model No. | eRigid M100w 150W |
| Feature | most popular size solar module |
| Product Name | solar panel 100w 150w for small solar system installation for home air conditioner |
| Maximum Power[Wp] | 100 |
| Solar Cell | mono solar cell solar panel 100w |
| Cell Array[Pcs] | 4*9 |
| Cell Efficiency | 22.5% |
| Size[mm] | 680*765*30mm |
| Ma* Power Voltage Vmp[V] | 20.52 |
| Ma* Power Current Imp[A] | 4.87 |
| Open Circuit Voltage Voc[V] | 24.15 |
| Short Circuit Current Isc[A] | 5.14 |
| Net.Weight[kg] | 6.3 |
| Power tolerance[%] | ±3% |
| NOCT[℃] | 45±2 |
